A Rechargeable 'Eye' on Your Weld Purge!

Our innovative PurgEye® 200 Weld Purge Monitor® now features PurgeNet™! As the world's first and only hand-held, rechargeable oxygen monitor, it measures accurately from 1,000 ppm (0.1%) down to 1 ppm (0.0001%) oxygen (accurate to 10 ppm). This groundbreaking technology in weld purge monitoring is designed to offer distributors a cutting-edge solution for their clients.

Why Choose Argweld® PurgEye® 200?

Precision and Reliability

Ensures high-quality, oxide-free welds with accurate oxygen level measurements down to 1 ppm.

Versatile Power Options

Offers the flexibility of rechargeable battery or mains power operation, making it suitable for various settings.

Advanced Features

Integration with PurgeNet™ and PurgeAlarm™ allows for seamless control and monitoring of welding processes.

Key Features and Benefits

Advanced Measurement and Display

Accurate Measurements: Measures oxygen levels from 1,000 ppm down to 1 ppm, with accuracy to 10 ppm, ensuring pristine, oxide-free welds.
OLED Display: The bright, clear OLED display offers sharper readings visible from longer distances and is mainly symbol-based for easy understanding across different languages.

Power and Durability

Rechargeable Battery: It operates on a rechargeable battery lasting up to 10 hours or 110/240V mains power. An optional charging dock is available.
IP65 Rated: Dustproof and moisture-resistant, ensuring robust performance in various environments.
Long Life Sensor: Features a fast response, long-life sensor with minimal maintenance.

PurgeNet™ Integration

PurgeNet™: Enables control of automatic welding machines and accessories such as orbital welders, traffic light indicators, and dew point meters.
PurgeAlarm™: Provides audio and visual alarms for rising or falling oxygen levels between 1 and 999 ppm, including an alarm mute and flow detection for accurate gas sample readings.

Technical Specifications

Measuring Range:

1,000 ppm to 1 ppm

Accuracy:

±10 ppm

Size:

225 mm (length) x 115 mm (widest point) x 40 mm (depth)

Weight::

400 grams (without batteries)

Power Consumption:

18 W

Operating Voltage:

AC 115/230 V single phase 50/60 Hz

Battery Life:

Up to 10 hours

Warm-Up Time:

2 minutes

Working Temperature:

0 to 70°C (32 to 158°F)

Ordering

Supplied With

Storage case
150 mm long red tube for purging exhaust
1 meter-long green tube with an inlet filter
Charging unit with international plug adapters
User instruction booklet
Calibration certificate for Quality Control Procedures and Management Systems

Accessories, Spares, and Replacements:

Gorilla Tripod
Camera Tripod
Sensor Removal Tool
Rubber Protective Cover

Dew Point Sensor

HFT®’s Dew Point Sensor can now be connected to the PurgEye® 200 via PurgeNet™ for accurate dew point measurement, essential for maintaining weld integrity. This sensor is compatible with all PurgEye® monitors reading down to 1 ppm, including:

- PurgEye® 200
- PurgEye® Desk
- PurgEye® 600
- PurgEye® 1000
- PurgEye® Site

Your Questions Answered

What is the intended application for the Argweld® PurgEye® 200 IP65 Weld Purge Monitor®?

This monitor is designed for extreme weld quality control in industries such as aerospace, semiconductor, pharmaceutical, vacuum, biotech, food and drinks, and any application demanding extremely accurate oxygen readings from the atmosphere down to 10 ppm.

Does the Argweld® PurgEye® 200 IP65 have a pump?

Yes, it includes an integral electro-mechanical pump.

What sort of sensor is used in the Argweld® PurgEye® 200 IP65?

The PurgEye® 200 IP65 uses a unique solid-state, long-life sensor, offering lower costs and high precision down to 10 ppm.

My company needs a calibration certificate for all instruments once a year. How do I obtain one?

We offer UK, USA, Singapore, and Norway calibration facilities. Contact us or your nearest distributor for pricing and arrangements. Calibration and certification are completed within a few days.

Is the Argweld® PurgEye® 200 IP65 Weld Purge Monitor® sensitive to electrical high-frequency disturbances?

The instrument has shielding to prevent most forms of interference, ensuring reliable performance.

Can I use the Argweld® PurgEye® 200 under high-temperature conditions?

The Argweld® PurgEye® 200 should not be exposed to gas above 50°C (122°F). Please contact us for information on exhaust purge gas cooling methods.

What is PurgeNet™?

PurgeNet™ controls welding power sources and other automatic welding systems, enabling them to switch on and off according to oxygen levels. It also facilitates data transfer to external devices.

Can Weld Purge Monitors® only be used when purging with argon?

The PurgEye® monitors measure oxygen levels within any gas, not just inert gases. They can be used with argon, helium, nitrogen, and nitrogen/hydrogen mixes.
